LS SWAPS: Oil Pan Guide. Once the motor mounts have been sorted out, the next step is to choose an oil pan. Many stock oil pans are available for LS engines, each one designed for a specific chassis. With so many different oil- pan options, there is confusion as to which oil pans fit which chassis. SHARE THIS ARTICLE: Please feel free to share this article on Facebook, in Forums, or with any Clubs you participate in. You can copy and paste this link to share: http: //lsenginediy. The relationship between the front crossmember and the motor mounts determines the fit of the oil pan.

Each brand of motor mount is different, and the engine- mount towers used on the frames can differ by application as well. Although there are several stock pans that fit certain vehicles, they don’t always fit as is, and there are different depths and clearances. In the end, there will probably be some trial- and- error test fitting to find just the right pan. The 1. 99. 8–2. 00. F- Body LS1 pan is the most commonly used LS oil pan. Typically referred to as the F- Body or Camaro pan, it works well with custom chassis crossmembers, and it is also the most frequently modified pan.
